Porcelain High Voltage Surge Arrester for Power Transmission / Distribution System

Porcelain High Voltage Surge Arrester for Power Transmission / Distribution System
Porcelain High Voltage Surge Arrester for Power Transmission / Distribution System

Duży Obraz :  Porcelain High Voltage Surge Arrester for Power Transmission / Distribution System

Szczegóły Produktu:

Place of Origin: Zhejiang,China(Mainland)
Nazwa handlowa: YONGDE
Orzecznictwo: ISO9001
Model Number: Y10W5-219

Zapłata:

Minimum Order Quantity: 1pcs
Cena: negotiation
Packaging Details: Wooden case
Delivery Time: 21days per container
Payment Terms: D/A, D/P, L/C, T/T, Western Union, MoneyGram, PayPal
Supply Ability: 1,500 pcs per month
Szczegółowy opis produktu
Type: Metal Oxide Surge Arrester Housed: Porcelain
Rated voltage: 219KV Nominal Current: 10KA
Function: Over-Voltage Protection Color: Customized
quality: high Standard: IEC60099-4
High Light:

high voltage lightning arrester

,

high voltage surge protector

High Voltage Polymeric Metal Oxide Surge Arrester for Substation​



Description:



Polymer Surge Arrester for 35~220kv alternating system

Main features: It adopts double sealing structure, the core encapsulates by molded silicone rubber which completely solves the sealing problem of porcelain housed products.
It has a two-way pressure release structure.
Its core component ZnO varistor has good pressure ratio, consistency, large flow capacity and high reliability.
E creepage distance of porcelain housed products is wide which is suitable for IV level heavy pollution areas.



Product characteristic:



Application: For protecting rated voltage up to 220kV power transmission &

distribution system from over-voltage.
Ratings: Up to 220kV.
Standards: IEC 60099-4
Features: Reliability and excellent protection based on years of experience and

expertise in surge protection. Good anti-moisture capability, resistant to pollution.

GIS metal oxide surge arrester, composite metal oxide surge arrester and porcelain

metal oxide surge arresters are available. Long life and lightweight. Easy installation

and maintenance. Good sealing capability to ensure reliable operation. High energy

absorption ability.



Specifications:



Type Nominal System Voltage Rated Voltage Continuous Operating Voltage MRV under 1/5 μ s Steeo Discharge Current MRV under 8/20 μ s Lightning Discharge Current MRV under 30/60 μ s Operating Discharge Current Minmum Reference Voltage under 1 mA DC 4/10 μ s High Current Impulse Twice (KA) 2mS SW through-flow capacity A/18 Line Discharge Class
5KA 10KA 5KA 10KA 0.25KA 0.5KA
Y10W5-192/500 220 192 150   560   500   426 280 100 800 3
Y10W5-200/520 220 200 156   582   520   442 290 100 800 3
Y10W5-204/532 220 204 159   594   532   452 296 100 800 3
Y10W5-216/562 220 216 168.5   630   562   478 314 100 800 3
